Suppliers 16MF panel mounted male socket GX16 4 pin 5pin 6pin round solder connector
| Coupling | Threaded coupling |
| Shell material | Zinc alloy with nikelplate |
| Contact material | copper( silver/ gold plated) |
| Insert material | bakelite |
| Rated current/voltage | 8A~30A 125V |
| Cable diameter | Ф7.5mm~ ≤ Ф 8.5 mm |
| Assemble way | assemble board |
| Solder cup mouth aperture | 0.8~1.2mm |
| Solder inter diameter | 1.2~1.6mm |
| Operation limit voltage(AC.V.rms) | 200 |
| Mating cycle | 500 |
| Temperature | -20℃~+85℃ |
| OEM | Yes,we accept |
| Delivery time | 3-45 days depends on buying stockage or OEM order |
