| No.of contacts | 2 | 3 | 4 | 5 | 6 | 7 |
| Rated current/voltage | 5A-125V | 5A-125V | 5A-125V | 5A-125V | 5A-125V | 5A-125V |
| Operation limit voltage(AC.V.rms) | 200 | 200 | 200 | 200 | 200 | 200 |
| withstanding voltage(AC.V.rms)1 minute | 1500 | 1500 | 1500 | 1500 | 1500 | 1500 |
| Insulation resistance at DC 500V | 1500 | 1500 | 1500 | 1500 | 1500 | 1500 |
| contact resistance AT DC 1A | 5 | 5 | 5 | 5 | 5 | 5 |
| Solder cup mouth aperture | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 |
| Solder inter diameter | 1.2 | 1.2 | 1.2 | 1.2 | 1.2 | 1.2 |
