Wholesales Electrical Connectors M12 Type
1.Product Introduction m12 connector 4 5 6 7 8 pin
This M12 type electrical connector, an electrical connector plug with the different contact number of 4pin,5pin and 8pins.Circular connectors are usually preferred in aerospace and industrial applications: they can be connected and disconnected without the use of coupling tools.The connector also has flame retardant and corrosion resistance, and the thickened process is adopted on the needle core.
2.Product Specification
| Material of Contact | Brass with Gold Plating |
| Material of Insert | PA66 |
| Cable Diameter | 4~6mm |
| Coupling | Threaded |
| Termination | Screw Connection |
| Connector Head | Straight / Right Angled |
| Nominal Current | Max 4A |
| Protection Degree | IP67 |
| Operating Temperature | -25℃~+85℃ |
3.Product Details
High Quality Shell: PA66 material shell, enhanced flame retardant.Thickened nylon resistant to presure and corrosion.
Brass with Gold Plating: To enhance electrical conductivity, thiken the pin, extend the life.
Screw Connection: Threaded cable, safe and reliable.Pure copper shock, excellent conductivity.
Fsat & Convenient: Nickel alloy, durable strong and sturdy. Gold-plateed brass contact, high conductivity performance.
Due to the high performance of this product, M12 electrical connector can be used in various fields, like industrial automation, food, pharmaceutical, automotive and lighting, etc.
