Product Features
The main reason for designing subconn underwater connectors at right angles is to meet the special needs of high watertight environments such as deep sea. Through structural innovation, right-angle seacon connectors achieve a balance between performance and practicality in high watertight and limited space scenarios.
1) Adapt to narrow space installation
The right-angle design can effectively solve the problem of narrow bulkhead space in deep-sea operations, ensure that optical fiber or pipeline connection is not restricted by bending, and achieve high watertightness.
2) Ensure the quality of optical fiber signal transmission
In deep-sea equipment, right-angle fiber optic connectors reduce cable bending and signal attenuation by optimizing the structure, ensuring communication stability and lossless transmission.
3) Improve sealing performance and reliability
Using threaded locking connection or precision sealing design, the right-angle structure can enhance the sealing of the connection part, adapt to high-pressure water environment, and extend service life.
4) Overcome the limitations of traditional design
Traditional circular or non-right-angle connectors are prone to failure due to insufficient installation space or poor sealing in deep-sea environments. The right-angle design overcomes these problems through structural optimization.
| Working Temperature |
-50℃~+100℃ |
| Rear-nut mount shell material |
316L Stainless steel |
| Rear-nut mount insert material |
Chloroprene rubber |
| Contact material |
Brass with gold plating |
| Rear-nut mount connector |
Teflon, silver plated pure copper |
| Cable connector |
Polyether cable for seabed with aluminum foil shielding |
| Mating cycle |
>500 times |
| Insulation resistance |
>0.01mΩ |
| Coupling |
Threaded |
| Termination |
Solder |
